detail pto ZF
Technical Specifications
| Code | Ratio | Torque Nm/Kgm | Speed rpm | Power Kw | Rotation | Control | Mounting | Connection |
|---|---|---|---|---|---|---|---|---|
| 935P5411DTKD | 1:1 | 479/49 | 513 | 26 | Right(cw) | Pneumatic | Rear | Iso |
| 937P5411ATKD | 1:1 | 479/49 | 513 | 26 | Right(cw) | Pneumatic | Rear | Iso |
| 935P5422DKCL | 1:1 | 286/29,2 | 540 | 20,3 | Left(ccw) | Pneumatic | Rear | Iso |
| 937P5422AKCL-1,33 | 1:1,33 | 343/35 | 560 | 20 | Left(ccw) | Pneumatic | Rear | Iso |
Other PTO's for
Accessories
Optional
-
Joysticks for PTO
-
Switches for PTO
-
Cable Controls for PTO
-
Washers for PTO
-
Studs and Nuts for PTO
Transmission: ZF ECOSPLIT 16 S151-181-221-251- (13,80-13,85-16,47-16,53-16,41) (B:213), 8 S151w16 S 2030, 16 S1930, 16 S1220, 16 S1620TD, 16 S1625 (13,80-16,47-16,53-16,41), 16 S1820T0-1825-1920TD-2220TD\TO, 16 S2520TO, 16 S2723, 12 S2220 (13,80-16,47-16,53-16,41) (B:213), 16 S2280, 16 S1685, 16 S2280, 8 S1620TD, 8 S1820 (11,54-0,84), 16 S2533T0, 12 AS2330 (12,33), 16 AS 2720, 16 AS 2330(16,41), 16 S 231, 16S 2320, 16 S2330, 12 S2130, 12 S2330, 12 S2830, 8 S1630, 16 S1630, 8 S1830, 16 S1830, 8 S1930, 16 S1930, 16 S2030, 8 S2230, 16 S2230, 16 S2530, 16 S2730
Vehicles; RENAULT KERAX-OPTIMUM-MAGNUM-MIDLUM 440/480.19; RENAULT 320/370.26/400.34; RENAULT PREMIUM: 370.32-420-400-440-480/ IVECO: 410E37-380E42-400E34-400E38-440E2-720E37- FE420A - FE19.420 (EUROTECH/ EUROTRAKKER/ EUROSTAR/ EUROTRONIC POWERSTAR/ CURSOR 380 4X4); STRALIS 260-400-430-440-540/ MAN: 14.463-17.322-19.422-423-426-464-26.310-372-373-422-32.310-33.372-33.423-40.423-40.463-41.423; FE 420A; MAN EUROPE 26.410-26.430-18.412-18.430-18.462 MAN TGA: 410-460(ABG)- 19.100; 18.410-14.460-18.490-39.390 (8X2)-40.423-41.360-41.423 MAN TGX: 18.440-19.400-26.440/ DAF: 75.310-85.360-85.400-85.410-95.500-85CF.340-95XF.380-95XF.430-95XF.480/ ASTRA: 1142/ HYUNDAI: HD 600-700-1000/ FORD CARGO: 1835-1838-3235-3936-3536-4136/ KAMAZ / MAZ
Cardan Shaft: C9311615 (Wera Hydraulic cardan shaft code)
